Optimizing an CNN for Speaker Recognition using Few Shot Training

Introduction Business at Maxim Integrated is focused on solving engineering problems to empower design innovation and create products that shape the world. One such application of this is wearable technology, or edge devices, where they aim to enhance portable devices by reducing size while increasing in power efficiency and sophistication. Edge devices serve a wide range of uses, though today’s interest in hands-free technology and automation make audio recognition a front runner.

Problem Statement Current standards in a popular subset of audio recognition known as speech recognition models present several barriers in their industry. The most common of which is the sheer volume requirement of data needed in order to attain acceptable levels of accuracy, often measured by the number of incorrect recognitions per alarm (known as false alarm rate). The most popular of such devices in this industry (such as Alexa, Google Assistant, and Siri) achieve low false alarm rates using computationally expensive models that require most small devices to send data to larger remote computers for executing, and sending the response back to the device, introducing two additional challenges – high computation power and internet connectivity. Indirectly, the use of cloud computation introduces security vulnerabilities (Tanui, Meshack, 2020).

Analysis Goals To overcome these challenges, we propose an artificial neural network for effective keyword and speaker recognition, leveraging unsupervised feature extraction, feature reduction, and distance metric learning methods, to suit Maxim Integrated’s low-bit and low-powered edge device using local computation. By leveraging local computation, we veer from the industry standard of cloud computation, providing increased data security and ownership. Further different from previous work, we’ll optimize our model to perform on fewer samples of audio, known as few shot learning, reducing the amount of data needed to achieve a high accuracy. An effective audio recognition model can correctly identify who a speaker is as well as what they said. With this two part goal in mind, we’ll minimize the false alarm error on two separate models: Speaker Identification and Keyword spotting. Speaker ID (SID) is a biometric verification technique in which the device is required to correctly recognize the identity of the speaker. In speaker identification, an utterance from an unknown speaker is analyzed and compared with speech models of known speakers. The unknown speaker is identified as the one whose model best matches the input utterance. If the match is good enough—that is, above a threshold—the claim is accepted (Furui, Sadaoki, 2010) . Keyword spotting (KWS) is a technique for recognizing certain spoken keywords, such as “Okay, Google” and “Hey Siri”. State-of-the-art SID and KWS systems are built using deep learning systems such as recurrent neural networks. But deploying these deep learning systems on the edge devices require a lot of memory and battery power to process the data locally. Maxim Integrated hardware aims to provide a wearable device with local computation as an alternative to the cloud computing devices that are standard today. By maximizing the trade-off of physical constraints of computing power and model accuracy, we deliver powerful audio recognition solutions to be implemented on Maxim Integrated’s specialized hardware.

Variables and Scope Key variables to be investigated therein include feature extraction methods, training sample size, and other neural network features that impact computational expense (GPU and RAM consumption) such as loss function. While we will be optimizing our models for the specific hardware provided by Maxim, as defined in this paper, we will not venture into hardware as variable, as it is outside the scope of this project.

Background Maxim Integrated is an edge-computing technology company that manufactures and sells a wide variety of high-performance analog and mixed-signal products and technologies. Maxim specializes in solving design challenges related to power efficiency for a wide range of machines from cars to wearable devices, miniaturization, and security on application-specific solutions in the automotive, manufacturing, healthcare, communications, and cloud computing industries.

Literature Review Few Shot Learning Awasthi et al. (2021) recognized the importance for KWS models to adapt to new classes using fewer samples, as providing extensive samples (for instance, over a 1000) is burdensome to users. They go on to implement a model requiring fewer samples (known as few shot KWS) to allow for on device customization and introduction of new words. The model’s performance is most improved by implementing a loss function. Local Computation Edge computing devices can ameliorate data privacy concerns in that they eliminate the risk of data leakages posed by moving data to the cloud (Mark Ryan 2010). Edge computing also reduces latency down to milliseconds while minimizing network bandwidth (Plastiras, George and Terzi 2018). Still, the most important problem is power saving so that these devices can work for days without charging. Any unnecessary data transfers, storage, or processing represents a waste of energy (Merenda and Massimo 2020). From the modeling perspective, the efficiency of the edge of computing devices can be enhanced by improving the model design and compression. Designing models with a reduced number of parameters (layers and neurons) can help reduce the memory and execution latency without sacrificing model accuracy. Several models have been optimized for deployment on edge devices, including Mobile Nets (Howard and Andrew 2017), Squeeze Nets (Iandola, Forrest and Han 2016). It’s important to have a smaller and efficient network to run the model on mobile devices - which has smaller memory and processing power. Siamese Networks The Siamese Neural network was introduced for the first time in the 1990s by Bromley and LeCun to solve signature verification as an image matching problem (Bromley and LeCun 1993). A siamese neural network consists of twin networks which accept distinct pairwise inputs but are joined by an energy function at the top. This function computes some metric between the highest-level feature representation on each side. The parameters between the twin networks are tied and shared with each other. Two key properties of the model, identical parallel layers structure and weight sharing, ensuring the consistency in the predictions. As such, the identical networks could not map two similar data points to very different locations in the feature space because each network uses the same weights and functions. If the audio is similar they should output the same results and if they are different they will output different results. This difference can be captured using different similarity metrics. Distance Metric Learning Killian Weinberg and Laurence Saul (2009) noted that traditional similarity models, like k nearest neighbors, rely heavily on the distance calculated between classes. In exploring several methods to exploit this margin, different outcomes can be obtained. The authors go on to posit that the ideal distance between labeled groups can be learned, rather than specified in advance, allowing the model to adapt and more accurately classify different labels. This concept proves to be an effective method for margin maximization and can improve model performance by increasing the separation between classes.

Data Data Sources To accomplish both KWS and SID, training data will be collected from multiple sources: Google, VoxCeleb and LibriSpeech. Each data source will provide two features: an mp3 clip (unstructured) and a text label (categorical). Google’s Speech Command Dataset will be leveraged for the initial keyword spotting. The dataset is composed of 65,000 one second long clips of 30 short words by thousands of different people via Google’s Do-it-Yourself Artificial Intelligence (AIY) website. The dataset is approximately 8.17 Gigabytes. Each label has both a numerical value and text description. For Speaker ID, training will occur on VoxCeleb2, a dataset of over 6,000 three second segments of 1 million utterances. Speech was extracted from interview videos uploaded to Youtube. LibriSpeech will be the final source of data training to improve performance in real world environments with background noise. LibriSpeech is a corpus of approximately 1000 hours of 16kHz read English speech. The data is derived from read audiobooks from the LibriVox project, and has been carefully segmented and aligned. This dataset contains audio from controlled environments with no external noise, just recording artifacts such as microphone buzz. Some of the limitations of this dataset are that we have to build a neural network model with Sparse Training Dataset, the Hardware limitation and trying to build a compact model. Assumptions The data leveraged in this project is pre-cleaned by the providing institutions. It is assumed that all utterances are correctly labeled. With the exception of Librispeech noisey dataset, all other utterances are collected from controlled environments without interfering sounds from unintended sources. Descriptive Analysis dataset contains audio from controlled environments with no external noise, just recording artifacts such as microphone buzz. Some of the limitations of this dataset are that we have to build a neural network model with Sparse Training Dataset, the Hardware limitation and trying to build a compact model.

Methodology Our proposed model will build on each of the approaches discussed in our literature review. Starting with data transformation, we compare several unsupervised feature extraction methods; reviewing the output feature structure of each method informs computation trade off decisions we’ll be making in the training stage. To minimize the amount of samples needed to adequately train our models, we’ll implement distance metric learning on the outputs of a siamese network, providing results that maximize the distance between similar classes (which we’ll call “friends” for the purpose of this paper) and different classes (or “foes”).We explore models using various sample sizes to train our model, and leave out all others for validation. Lastly, to assess the generalizability of our model to unseen data, we use the validation samples in addition to real-world data collected from our community to obtain false alarm rates on models trained on the different sample sizes. To measure our model’s improvement on current industry standards (leveraging computationally expensive processes and networks requiring a large amount of training data), we’ll first create a convolutional neural network to establish a baseline model with different sample sizes (200, 100, 50, 25, 10, 5, 2 samples in each category). This will inform us not only of the accuracy score to be beat, but also of where the training sample size begins to impact performance, indicating where few shot learning methods will be beneficial. With such sample size identified, we will introduce a Siamese neural network, a class of CNN, to counteract the performance deficit identified with few shot samples. Finally, our SID and KWS models can be combined to provide a speaker-aware KWS system that performs with maximum precision and less false alarms per hour. Feature Engineering The nature of sound signal data is complex, containing not only signals, but also information about the speaker, language, and noise. This complexity requires extensive segmentation and feature extraction to obtain quantifiable representations to feed into machine learning models. Various methods to accomplish this have been established in audio recognition and yield different results. Because we do not know which method will provide the best response for our use case, we’ll explore several options in our baseline models. FairSeq Similar to work by Schneider, Baevski, Collobert, and Auli, we will explore an unsupervised feature extraction method, FairSeq, before strengthening our models with supervised training. FairSeq uses a Wav2vec network to extract features in a two step process. The first step is running sound wave data through an encoder that embeds the signal in latent space, which allows for similar data points to be represented by proximity to one another. The second step involves feeding the information to the transformer. Mel Frequency Ceptral Coefficients Like Wav2vec, Mel Frequency Ceptral Coefficients (MFCC) is another common method of signal processing, with the goal being to transform a speech waveform into a parametric representation (Rashidul Hasan, Mustafa Jamil, Golam Rabbani, and Saifur Rahman). Audio data can be truncated into 5-100 millisecond sound bytes and fed into an MFCC network and transformed into a series of feature vectors. Sound bytes of this size are considered quasi-stationary and exhibit little change in sound wave. To create the feature vectors, sound is transformed to the Mel Frequency Scale which is composed of two primary features: linear frequency spacing for sounds below 1000 Hz and logarithmic spacing for sounds over that threshold. PCA Both MFCC and FairSeq feature creation methods result in high dimensional outputs. To counterbalance the size of these outputs and reduce stress on computational constraints, we explored model performance of these techniques in combination with principal component analysis, or PCA. PCA allows us to prune high dimensional outputs down by removing insignificant features, leaving the most necessary and heavily utilized features behind for further processing.

Modeling Framework Architecture For consistency with Maxim Integrated’s AI architecture, executable files will organize our train and validation processes into 1) Retrieving, extracting and augmenting data sources, 2) Initializing PyTorch models leveraging Maxim’s custom PyTorch Library, ai8x, 3) Model Training, and 4.) measuring computational expenses and validating performance. Following Maxim’s architecture will ease company adoption of the models developed for this project and ensure smooth implementation. The nature of the pytorch, neural networks and sheer size of training datasets requires that model training takes place over hardware equipped with Ubuntu Linux 20.04. Hardware acceleration is highly recommended. For consistent computing without local hardware limitations, data will be stored and processed using a secure remote computer provided by Maxim. Baseline Models The CNN baseline performance was established using three iterations of 4-layer CNN, varying feature extraction methods. This provided us with insights on the performance of models using FairSeq, MFCC, and Fairseq with PCA. For each iteration, we used a batch size of 64, a learning rate of .01, and trained for 20 epochs. The first iteration of FairSeq based model has around 512 feature spaces,while the MFCC model contains around 20 features and the combined FairSeq PCA model comprises about 81 features. The 81 features in the FairSeq PCA model explain around 90% variance. For all of these models, we added dropouts on all the layers, in order for it to be generalized. In comparing model performance on test accuracy, FairSeq with PCA performs best. From this baseline, we implement our siamese network with distance metric learning on the initial FairSeq PCA model.

Conclusion The accuracy improvement of combined methodologies of FairSeq, PCA and Siamese over traditional models prove worth deeper exploration and implementation in the audio recognition space. Combining Distance Metric Learning techniques with shallow neural networks improves the ability of neural networks to differentiate classes of the same type from classes of different types, as indicated by the greater difference in similarity metrics. Resource heavy networks, like the more traditional CNN’s used in KWS models, begin to fail when training samples are reduced below 20. While this is expected in neural networks, as they favor large amounts of training data, it’s impractical and burdensome to users to provide over 20 samples of a keyword. By leveraging a siamese keyword spotting model, not only is the burden on users reduced without sacrificing model performance, but the added inconveniences and risks of cloud based competitors is also avoided.

Recommendations Future work is recommended on integrating KWS models for a speaker aware few shot keyword spotting model. Expanding model training and tuning on new sources of data, such as real-world collections would be a reasonable next step. Joining KWS models with additional audio recognition tools such as Speaker Identification and Noise Suppression would further improve the performance of audio recognition devices.

References Bromley, Jane, James Bentz, Léon Bottou, Isabelle Guyon, Yann LeCun, Cliff Moore, Eduard Säckinger, and Roopak Shah. “Signature Verification Using a ‘Siamese’ Time Delay Neural …” Accessed November 3, 2021. https://proceedings.neurips.cc/paper/1993/file/288cc0ff022877bd3df94bc9360b9c5d-Pap er.pdf. Felzenszwalb, Pedro, Ross Girshick, David McAllester, and Deva Ramanan. “Object Detection with Discriminatively Trained Part Based Models.” IEEE Xplore . Accessed November 3, 2021. https://ieeexplore.ieee.org/document/5255236/. Furui, Sadaoki. “Speaker recognition in smart environments.” In Human-Centric Interfaces for Ambient Intelligence, pp. 163-184. Academic Press, 2010. Gales, Mark, and Steve Young. “The Application of Hidden Markov Models in Speech Recognition.” Foundations and Trends in Signal Processing. Accessed November 3, 2021. http://www.nowpublishers.com/article/DownloadSummary/SIG-004. Gartner_Inc. “Forecast: Internet of Things - Endpoints and Associated Services, Worldwide, 2017.” Gartner. Accessed November 3, 2021. https://www.gartner.com/en/documents/3840665/forecast-internet-of-things-endpoints-an d-associated-ser. Geron, Aurelien. “Hands-on Machine Learning with Scikit-Learn and Tensorflow.” Accessed November 3, 2021. https://upload.houchangtech.com/pdf/Hands-on_Machine_Learning.pdf. Gu, Jiuxiang, Zhenhua Wang, Jason Kuen, Lianyang Ma, Amir Shahroudy, Bing Shuai, Ting Liu, et al. “Recent Advances in Convolutional Neural Networks.” Pattern Recognition. Pergamon, October 11, 2017. https://www.sciencedirect.com/science/article/abs/pii/S0031320317304120. Han, Song, Huizi Mao, and William J. Dally. “Deep Compression: Compressing Deep Neural Networks with Pruning, Trained Quantization and Huffman Coding.” arXiv.org, January 19, 2016. https://arxiv.org/abs/1510.00149v4. Hasan, Md & Jamil, Mustafa & Rabbani, Golam & Rahman, Md. Saifur. (2004). Speaker Identification Using Mel Frequency Cepstral Coefficients. Proceedings of the 3rd International Conference on Electrical and Computer Engineering (ICECE 2004). He, Kaiming, Xiangyu Zhang, Shaoqing Ren, and Jian Sun. “Deep Residual Learning for Image Recognition.” arXiv.org, December 10, 2015. https://arxiv.org/abs/1512.03385. Hinton, Geoffrey, Oriol Vinyals, and Jeff Dean. “Distilling the Knowledge in a Neural Network.” arXiv.org, March 9, 2015. https://arxiv.org/abs/1503.02531. Howard, Andrew G., Menglong Zhu, Bo Chen, Dmitry Kalenichenko, Weijun Wang, Tobias Weyand, Marco Andreetto, and Hartwig Adam. “MobileNets: Efficient Convolutional Neural Networks for Mobile Vision Applications.” arXiv.org, April 17, 2017. https://arxiv.org/abs/1704.04861. Iandola, Forrest N., Song Han, Matthew W. Moskewicz, Khalid Ashraf, William J. Dally, and Kurt Keutzer. “Squeezenet: Alexnet-Level Accuracy with 50x Fewer Parameters and <0.5MB Model Size.” arXiv.org, April 6, 2016. https://arxiv.org/abs/1602.07360v3. Koch, Gregory, Richard Zemel, and Ruslan Salakhutdinov. “Siamese Neural Networks for One-Shot Image Recognition.” Department of Computer Science, University of Toronto. Accessed November 3, 2021. https://www.cs.cmu.edu/~rsalakhu/papers/oneshot1.pdf. Merenda, Massimo, Carlo Porcaro, and Demetrio Iero. “Edge Machine Learning for AI-Enabled IOT Devices: A Review.” MDPI. Multidisciplinary Digital Publishing Institute, April 29, 2020. https://www.mdpi.com/1424-8220/20/9/2533. Plastiras, George, Maria Terzi, Christos Kyrkou, and Theocharis Theocharidcs. “Edge intelligence: Challenges and opportunities of near-sensor machine learning applications.” In 2018 IEEE 29th international conference on application-specific systems, architectures and processors (asap), pp. 1-7. IEEE, 2018. Ravi, S, Larochelle, H. (n.d.). Optimization as a model for few-shot learning - openreview. Retrieved February 23, 2022, from https://openreview.net/pdf?id=rJY0-Kcll Ryan, Mark D. “Cloud computing privacy concerns on our doorstep.” Communications of the ACM 54, no. 1 (2011): 36-38. Schneider, Steffen, Alexei Baevski, Ronan Collobert, and Michael Auli. (2020, June 10). Deep learning with Bert on azure ML for text classification. TECHCOMMUNITY.MICROSOFT.COM. Retrieved February 23, 2022, from https://techcommunity.microsoft.com/t5/ai-customer-engineering-team/deep-learning-wit h-bert-on-azure-ml-for-text-classification/ba-p/1149262 Tanui, Meshack. “Insecurity in the Internet of Things-Amazon Alexa.” (2020) Weinberger, Killian, and Lawrence Saul. (2009). Distance metric learning for large margin nearest neighbor Classification. Journal of Machine Learning Research. Retrieved February 24, 2022, from https://jmlr.csail.mit.edu/papers/volume10/weinberger09a/weinberger09a.pdf
